Double Strand


Intl. Ref. No.	Diamond Chain No.	Pitch (P)	Width Betwwen Inner Plates (W) (Min)	Roller Dia (D) (Max)	Bearing Pin Dia (D) (Max)	Plate Height (H) (Max)	Width Over Bearing Pin (A) (Max)	Width Over Joint Fastener (B) (Max)	Transveres Pitch(P1)	Tensile Strength (Kgf) (Min)
C08B	D083 02 ST 01	12.70	7.75	8.51	4.45	11.80	31.00	34.90	13.92	3270
C10B	D101 02 ST 01	15.875	9.65	10.16	5.08	14.70	36.20	40.30	16.59	4540
C12B	D120 02 ST 01	19.05	11.68	12.07	5.72	16.10	42.20	46.80	19.46	5900
C16B	D160 02 ST 01	25.40	17.02	15.88	8.27	24.10	68.00	73.40	31.88	11600
	D160 02 ST 02	25.40	17.02	15.88	8.27	20.58	68.00	73.40	31.88	11600
C20B	D200 02 ST 01	31.75	19.56	19.05	10.19	26.40	79.00	85.10	36.45	17330
C24B	D240 02 ST 01	38.10	25.40	25.40	14.63	33.40	101.00	107.60	48.36	28850
C28B	D280 02 ST 01	44.45	30.99	27.94	15.90	37.00	124.00	131.40	59.56	36700
C32B	D320 02 ST 01	50.80	30.99	29.21	17.81	42.20	126.00	133.90	58.55	45880

Triple Strand


Intl. Ref. No.	Diamond Chain No.	Pitch (P)	Width Betwwen Inner Plates (W) (Min)	Roller Dia (D) (Max)	Bearing Pin Dia (D) (Max)	Plate Height (H) (Max)	Width Over Bearing Pin (A) (Max)	Width Over Joint Fastener (B) (Max)	Transveres Pitch(P1)	Tensile Strength (Kgf) (Min)
C08B	D083 03 ST 01	12.70	7.75	8.51	4.45	11.80	44.90	48.80	13.92	4850
C10B	D101 03 ST 01	15.875	9.65	10.16	5.08	14.70	52.80	56.90	16.59	6810
C12B	D120 03 ST 01	19.05	11.68	12.07	5.72	16.10	61.70	66.30	19.46	8850
C16B	D160 03 ST 01	25.40	17.02	15.88	8.27	24.10	99.00	105.30	31.88	17400
	D160 03 ST 02	25.40	17.02	15.88	8.27	20.58	99.90	105.30	31.88	17400
C20B	D200 03 ST 01	31.75	19.56	19.05	10.19	26.40	116.00	122.10	36.45	25490
C24B	D240 03 ST 01	38.10	25.40	25.40	14.63	33.40	150.00	156.60	48.36	43330
C28B	D280 03 ST 01	44.45	30.99	27.94	15.90	37.00	184.00	191.40	59.56	54040
C32B	D320 03 ST 01	50.80	30.99	29.21	17.81	42.20	281.00	291.00	58.55	68320
